Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Case/Package | TO-220-3 |
Voltage Rating (DC) | -300 V |
Current Rating | 1.00 A |
Polarity | PNP |
Power Dissipation | 40 W |
Breakdown Voltage (Collector to Emitter) | 300 V |
Continuous Collector Current | 1A |
hFE Min | 30 @300mA, 10V |
hFE Max | 150 |
Input Power (Max) | 40 W |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -65 ℃ |
Show | |
Size-Length | 10.28 mm |
Size-Width | 4.82 mm |
Size-Height | 9.28 mm |
Operating Temperature | -65℃ ~ 150℃ (TJ) |
Product Lifecycle Status | Unknown |
Packaging | Tube |
Minimum Packing Quantity | 50 |
RoHS | Non-Compliant |
Lead-Free Status | Contains Lead |
