Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 6 Pin |
Case/Package | PDIP-6 |
Input Voltage (DC) | 1.15 V |
Output Voltage | ≤400 V |
Number of Circuits | 1 Circuit |
Number of Channels | 1 Channel |
Number of Positions | 6 Position |
Forward Voltage | 1.15 V |
Power Dissipation | 300 mW |
Isolation Voltage | 5000 Vrms |
Holding Current | 250 µA |
Forward Current | 50 mA |
Output Voltage (Max) | 280 VAC |
Input Current (Min) | 50 mA |
Reverse Breakdown Voltage | 6 V |
Maximum Forward Voltage (Max) | 1.5 V |
Forward Current (Max) | 50 mA |
Operating Temperature (Max) | 100 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 330 mW |
Show | |
Size-Length | 7.3 mm |
Size-Width | 6.5 mm |
Size-Height | 3.5 mm |
Operating Temperature | -40℃ ~ 100℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
