Description

The NC7SZ74L8X is a single CMOS D-type Flip-flop with preset and clear from Fairchild"s ultra-high-speed series of TinyLogic®. The device is fabricated with advanced CMOS technology to achieve ultra-high speed with high output drive, while maintaining low static power dissipation over a very broad VCC operating range of 1.65 to 5.5V VCC. The inputs and outputs are high impedance when VCC is 0V. Inputs tolerate voltages up to 7V, independent of VCC operating voltage. The signal level applied to the D input is transferred to the Q output during the positive-going transition of the clock pulse.
Power down high impedance inputs/output
Over-voltage tolerance inputs facilitate 5 to 3V translation
Proprietary Noise/EMI reduction circuitry
2.6ns typical into 50pF at 5V VCC Ultra-high speed

Show

NC7SZ74L8X Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	UFQFN-8
Frequency	250 MHz
Supply Voltage (DC)	1.65V (min)
Number of Outputs	1 Output
Number of Circuits	1 Circuit
Number of Positions	8 Position
Clock Speed	200 MHz
Number of Bits	1 Bit
Polarity	Non-Inverting, Inverting
Input Capacitance	3 pF
Number of Inputs	1 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	1.65V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	1.65 V
	Show
Size-Length	1.6 mm
Size-Width	1.6 mm
Size-Height	0.5 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
