NCP785AH120T1G - ON Semiconductor
Manufacturer:
ON Semiconductor
ManyChip's Part#:
MC8841707
Category:
Voltage Regulator
Package:
SOT-89-3
Datasheet:
Datasheet 3D Model
Description:
ON SEMICONDUCTOR NCP785AH120T1G Linear Voltage Regulator, Fixed, 55VDC To 450VDC In, 12V And 10mA Out, SOT-89-3
Stock Locations:
Availability:
1,210 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.68

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The NCP785AH120T1G is a high-performance Linear Regulator with 12V output voltage. It is offering a very wide operating input voltage range of up to 450VDC with an output current of up to 10mA. Ideal for high input voltage applications such as industrial and home metering, home appliances. The device offers ±5% initial accuracy, extremely high-power supply rejection ratio and ultra-low quiescent current. The device is optimized for high-voltage line and load transients, making this part ideal for harsh environment applications.
Thermal shutdown and current limit protection
Stable with ceramic output capacitor 22µF MLCC
70dB at 60Hz, 90dB at 100kHz Ultra-high PSRR

Show

NCP785AH120T1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-89-3
Number of Outputs	1 Output
Output Voltage	12 V
Output Current	10 mA
Number of Positions	3 Position
Quiescent Current	22 µA
Input Voltage (Max)	450 V
Input Voltage (Min)	55 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	±5 %
Input Voltage	55V ~ 450V
	Show
Size-Length	4.6 mm
Size-Width	2.6 mm
Size-Height	1.6 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
