Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 3 Pin |
Case/Package | TO-3-3 |
Frequency | 30 MHz |
Number of Positions | 3 Position |
Polarity | PNP, P-Channel |
Power Dissipation | 150 W |
Breakdown Voltage (Collector to Emitter) | 250 V |
Continuous Collector Current | 15A |
hFE Min | 75 @3A, 5V |
hFE Max | 150 |
Input Power (Max) | 150 W |
DC Current Gain (hFE) | 75 |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -65 ℃ |
Power Dissipation (Max) | 150000 mW |
Show | |
Size-Length | 15.8 mm |
Size-Width | 5 mm |
Size-Height | 20.1 mm |
Material | Silicon |
Operating Temperature | -65℃ ~ 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/12/17 |
ECCN Code | EAR99 |
