Description

This device is designed for applications requiring Line Terminations, EMI Filtering and ESD Protection. It is intended for use in downstream USB 1.1 ports, Celluar phones, Wireless equipment and computer applications. This device offers an integrated solution in a small package (TSOP-6, Case 318G) reducing PCB space and cost.
Features
---
|
Provides USB Line Termination, Filtering and ESD Protection
Single IC Offers Cost Savings by Replacing 4 Resistors, 2 Capacitors, and 5 TVs Diodes
EMI Filtering Prevents Noise from Entering/Leaving the System
IEC61000-4-2 ESD Protection for USB Port
ESD Ratings: Machine Model=C, Human Body Model=3B
Pb-Free Package is available

Show

NUF2101MT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	TSOP-6
Voltage Rating (DC)	5.25 V
Operating Voltage	5.25 V
Current Rating	100 A
Capacitance	55.0 pF
Power Rating	225 mW
Halogen Free Status	Halogen Free
Number of Channels	3 Channel
Number of Positions	6 Position
Power Dissipation	0.225 W
Shielding	No
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
	Show
Size-Length	3.1 mm
Size-Width	1.7 mm
Size-Height	1.1 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
