Image is for your reference only,please check specifications for details
- OPA320SAIDBVR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC44639200
-
Category:Operational Amplifier, OP Amp IC
-
Package:SOT-23-6
-
Datasheet:Datasheet 3D Model
-
Description:Precision, 20MHz, 0.9pA Ib, RRIO, CMOS Operational Amplifier 6-SOT-23 -40℃ to 125℃
-
Stock Locations:
-
Availability:291 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 3.67
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- DESCRIPTION
- The OPA320 (single) and OPA2320 (dual) are a new generation of precision, low-voltage CMOS operational amplifiers optimized for very low noise and wide bandwidth while operating on a low quiescent current of only 1.45mA.
- FEATURES
- • Precision with Zero-Crossover Distortion:
- – Low Offset Voltage: 150μV (max)
- – High CMRR: 114dB
- – Rail-to-Rail I/O
- • Low Input Bias Current: 0.9pA (max)
- • Low Noise: 7nV/√Hz at 10kHz
- • Wide Bandwidth: 20MHz
- • Slew Rate: 10V/μs
- • Quiescent Current: 1.45mA/ch
- • Single-Supply Voltage Range: 1.8V to 5.5V
- • OPA320S, OPA2320S:
- – IQ in Shutdown Mode: 0.1μA
- • Unity-Gain Stable
- • Small Packages:
- – SOT23, MSOP, DFN
- APPLICATIONS
- • High-Z Sensor Signal Conditioning
- • Transimpedance Amplifiers
- • Test and Measurement Equipment
- • Programmable Logic Controllers (PLCs)
- • Motor Control Loops
- • Communications
- • Input/Output ADC/DAC Buffers
- • Active Filters
OPA320SAIDBVR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 6 Pin |
| Case/Package | SOT-23-6 |
| Supply Current | 1.5 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Common Mode Rejection Ratio | 100 dB |
| Input Offset Drift | 1.50 µV/K |
| Slew Rate | 10.0 V/μs |
| Gain Bandwidth Product | 20 MHz |
| Input Offset Voltage | 40 µV |
| Input Bias Current | .2 pA |
| Gain Bandwidth | 20 MHz |
| Minimum CMRR Range | 100 dB |
| Show | |
| Operating Temperature | -40℃ ~ 150℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
