Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Voltage Rating (DC) | 250 V |
Orientation | Vertical |
Inductance | 10 mH |
Current Rating (Max) | 700 mA |
Operating Temperature (Max) | 60 ℃ |
Operating Temperature (Min) | -25 ℃ |
Voltage Rating | 250 VAC |
Resistance (DC Max) | 860 mΩ |
Show | |
Size-Length | 18 mm |
Size-Width | 16 mm |
Size-Height | 17.5 mm |
Weight | 6.8 g |
Operating Temperature | -25℃ ~ 60℃ |
Product Lifecycle Status | Discontinued at Digi-Key |
Packaging | Box |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
