Description
- The PTN78020WAD is a 90W Non-isolated Adjustable Switching Regulator with wide output voltage and wide input voltage range. It is smaller and lighter than its predecessors and has either similar or improved electrical performance characteristics. This provides high efficiency and output voltage is set using a single external resistor. This module is suited to a wide variety of general-purpose applications.
- High efficiency up to 96%
- On/off inhibit
- Under-voltage lockout (UVLO)
- Output current limit
- Over-temperature protection
- -40 to +85°C Operating temperature range
PTN78020WAD Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 7 Pin |
| Case/Package | DIP-7 |
| Frequency | 550 kHz |
| Supply Voltage (DC) | 20.0 V |
| Power Rating | 75 W |
| Number of Outputs | 1 Output |
| Input Voltage (DC) | 7.00V ~ 36.0V |
| Output Voltage | 2.5V ~ 12.6V |
| Output Current | 6 A |
| Number of Regulated Outputs | 1 Output |
| Output Power | 90 W |
| Switching Frequency | 440kHz ~ 660kHz |
| Topology | Buck |
| Input Voltage (Max) | 36 V |
| Input Voltage (Min) | 7 V |
| Input Voltage (DC Max) | 36 V |
| Input Voltage (DC Min) | 7 v |
| Output Voltage (Max) | 12.6 V |
| Output Voltage (Min) | 2.5 V |
| Output Current (Max) | 6 A |
| Input Power (Max) | 90 W |
| Input Power (Max) | 75.6 W |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 7V ~ 36V |
| Show | |
| Size-Length | 37.97 mm |
| Size-Width | 22.1 mm |
| Size-Height | 9 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
