Description
- The PVN012PBF is a HEXFET® Power MOSFET Photovoltaic Relay with SPST-NO contact and through hole terminals. This PVN012-series relay features high load current capacity and high off-state resistance. Linear AC/DC operation. It utilizes a GenerationV HEXFET output switch, driven by an integrated circuit photovoltaic generator of novel construction. The output switch is controlled by radiation from a GaAlAs light emitting diode (LED) which is optically isolated from the photovoltaic generator. These units exceed the performance capabilities of electromechanical relays in operating life, sensitivity, stable on-resistance, miniaturization, magnetic insensitivity and ruggedness. They are ideally suited for switching high currents or low level signals without distortion or injection of electrical noise.
- Bounce-free operation
- Solid state reliability
- 5ms Turn-on and 0.5ms Turn-off Maximum time
- -40 to 85°C Ambient operating temperature range
PVN012PBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 6 Pin |
| Case/Package | DIP-6 |
| Current Rating | 4.5 A |
| Capacitance | 300 pF |
| Output Current | 2.5 A |
| Contacts Type | SPST-NO |
| Number of Channels | 1 Channel |
| Load Current | 2.5 A |
| Number of Positions | 6 Position |
| Rise Time | 5 ms |
| Isolation Voltage | 4 kV |
| Forward Current | 25 mA |
| Output Voltage (Max) | 20 V |
| Input Current (Min) | 25 mA |
| Fall Time | 0.5 ms |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Voltage Rating | 20 VDC |
| Input Voltage | 1.2 VDC |
| Show | |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
