Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 6 Pin |
Case/Package | SOT-23-6 |
Operating Voltage | 6 V |
Capacitance | 3.5 pF |
Breakdown Voltage | 6 V |
Number of Circuits | 2 Circuit |
Number of Channels | 2 Channel |
Number of Positions | 6 Position |
Power Dissipation | 85 W |
Data Rate | 480 Mbps |
Clamping Voltage | 17 V |
Test Current | 1 mA |
Min Breakdown Voltage | 6 V |
Reverse Breakdown Voltage | 6 V |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -40 ℃ |
Show | |
Size-Length | 3.05 mm |
Size-Width | 1.75 mm |
Size-Height | 1.3 mm |
Operating Temperature | -40℃ ~ 125℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2014/06/16 |
ECCN Code | EAR99 |
HK STC License | NLR |
