Image is for your reference only,please check specifications for details

PX0446 - Bulgin Components
Manufacturer:
Bulgin Components
ManyChip's Part#:
MC18327968
Category:
Computer Cable
Datasheet:
Datasheet 3D Model
Description:
BULGIN PX0446 Computer Cable, Connector, Rear Panel Mount, USB Mini B, Crimp Terminal, 0.45Ft, Black
Stock Locations:
Availability:
0 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The PX0446 from Bulgin is a mini USB B type Buccaneer rear panel mounting connector. This mini USB Buccaneer provides compact solution for USB connections utilising the industry standard mini B connection for panel connection. It offers secure and robust connection performing to USB V2.0 where dust or water could prove detrimental to system operation. The system is fully shielded providing good levels of noise immunity and EMI protection. It has overmoulded construction offering secure, tamper proof connections.
Leaded with 5 way header
Mates with PX0441 and PX0442 type cables
IP68 rated
Data rates up to 400Mbs
High noise immunity
Voltage rating of 30VAC and 42VDC
Current rating of 1A
Temperature rating from 0°C to 70°C

Show

PX0446 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Panel
Number of Contacts	5 Contact
Gender	Female
Contact Plating	Gold
Voltage Rating (AC)	30.0 V
Current Rating	1 A
Flammability Rating	UL 94 V-0
Data Rate	400 Mbps
Number of Mating Cycles	5000 Cycle
Number of Conductors	5 Conductor
Current Rating (Max)	1 A
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Voltage Rating	42 V
	Show
Size-Length	107 mm
Cable Length	0.107 m
Color	Black
Contact Material	Copper Alloy
Operating Temperature	-20℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
HTS Code	8544429090
ECCN Code	EAR99
