Description

The SG3524P voltage mode PWM controller from STMicroelectronics will help you out when you need to encode messages. With an output that has a voltage of 18 V, this is power management at its best. This voltage mode driver supports push-pull topology. Its 2 PWM outputs produce a current of 100 mA. It has a switching frequency of 300 kHz. This device has a minimum operating supply voltage of 8 V and a maximum of 40 V. This voltage mode driver has an operating temperature range of 0 °C to 70 °C. This voltage mode driver"s maximum duty cycle is 45 %.

Show

SG3524P Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Frequency	300 kHz
Supply Voltage (DC)	8.00V (min)
Number of Outputs	2 Output
Input Voltage (DC)	40.0 V
Output Voltage	18 V
Output Current	100 mA
Number of Positions	16 Position
Power Dissipation	1000 mW
Quiescent Current	8.00 mA
Rise Time	200 ns
Switching Frequency	300 kHz
Duty Cycle	45 %
Maximum Duty Cycle	45 %
Fall Time	100 ns
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	1000 mW
Supply Voltage	8V ~ 40V
Supply Voltage (Max)	40 V
Supply Voltage (Min)	8 V
Input Voltage	40 V
	Show
Size-Length	10 mm
Size-Width	4 mm
Size-Height	1.65 mm
Operating Temperature	0℃ ~ 70℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
