SN74AVC2T244DQMR - TI
Manufacturer:
TI
ManyChip's Part#:
MC1827538
Category:
Voltage Level Translator IC
Package:
XFDFN-8
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS SN74AVC2T244DQMR Voltage Level Translator, AVC Family, 2Input, 24mA, 20ns, 900mV to 3.6V, X2SON-8
Stock Locations:
Availability:
272 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.67

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The SN74AVC2T244DQMR is a dual-bit dual-supply Bus Transceiver uses two separate configurable power-supply rails. The A port is designed to track VCCA. VCCA accepts any supply voltage from 0.9 to 3.6V. The B port is designed to track VCCB. VCCB accepts any supply voltage from 0.9 to 3.6V. For the SN74AVC2T244, when the OE\ input is high, all outputs are placed in the high-impedance state. The SN74AVC2T244 is designed so that the OE\ input circuit is referenced to VCCA. This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.
6µA Maximum ICC low static-power consumption
OE feature allows user to disable outputs to reduce power consumption
±24mA Output drive at 3V
Ioff Supports partial power-down-mode operation
Input hysteresis allows slow input transition and better switching noise immunity at input
Latch-up performance exceeds 100mA per JESD78 class II
Green product and no Sb/Br

Show

SN74AVC2T244DQMR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	XFDFN-8
Supply Voltage (DC)	1.10V ~ 3.60V
Number of Outputs	2 Output
Output Current	24 mA
Number of Circuits	1 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Number of Bits	2 Bit
Propagation Delay Max (tpd)	3.70 ns
Static Current	5.00 µA
Output Current Drive	24.0 mA
Number of Inputs	2 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Number of Output Channels	1 Channel
Supply Voltage	0.9V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	0.9 V
	Show
Size-Length	1.85 mm
Size-Width	1.25 mm
Size-Height	0.35 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
