Description

The STPS1045D is a single chip Schottky Power Rectifier suitable for SWITCHMODE™ power supply and high frequency DC to DC converters. This device is intended for use in low voltage, high frequency inverters, free-wheeling and polarity protection applications.
Very small conduction losses
Negligible switching losses
Extremely fast switching
Low forward voltage drop
Avalanche capability specified

Show

STPS1045D Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	TO-220-2
Voltage Rating (DC)	45.0 V
Current Rating	10.0 A
Output Current	≤10.0 A
Load Current	10 A
Number of Positions	2 Position
Forward Voltage	600mV @10A
Polarity	Standard
Thermal Resistance	2.2℃/W (RθJC)
Forward Current	10 A
Max Forward Surge Current (Ifsm)	180 A
Maximum Forward Voltage (Max)	600 mV
Forward Current (Max)	10 A
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	175℃ (Max)
Junction Temperature (Max)	175 ℃
	Show
Size-Length	10.4 mm
Size-Width	4.6 mm
Size-Height	9.15 mm
Operating Temperature	175 ℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
