Description
- Bipolar Motor Driver Power MOSFET Parallel 25-HZIP
TB6560AHQ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 25 Pin |
| Case/Package | HZIP-25 |
| Output Voltage | 40 V |
| Output Current | 3 A |
| Number of Channels | 1 Channel |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -30 ℃ |
| Power Dissipation (Max) | 43000 mW |
| Supply Voltage | 4.5V ~ 5.5V |
| Input Voltage | 0.5.5 V |
| Show | |
| Operating Temperature | -30℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| HK STC License | NLR |
