Description

The TC4S01F is 2-input positive logic NOR gates. Gate output with inverter buffer improve the input-output characteristics and even if the load capacitance increase,it can be stopped the change of propagation time

Show

TC4S01F Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Case/Package	SSOP-5
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	40 ℃
Supply Voltage (Max)	18 V
Supply Voltage (Min)	3 V
	Show
Size-Length	2.9 mm
Size-Width	1.6 mm
Size-Height	1.1 mm
Product Lifecycle Status	Not Recommended for New Designs
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
HK STC License	NLR
