Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 3 Pin |
Case/Package | SOT-23-3 |
Breakdown Voltage | 75.0 V |
Forward Voltage | 1.25 V |
Reverse recovery time | 4 ns |
Max Forward Surge Current (Ifsm) | 4 A |
Maximum Forward Voltage (Max) | 1.25V @150mA |
Forward Current (Max) | 215 mA |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -65 ℃ |
Junction Temperature | 150℃ (Max) |
Show | |
Size-Length | 3 mm |
Size-Width | 1.4 mm |
Size-Height | 1 mm |
Product Lifecycle Status | Unknown |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HK STC License | NLR |
