Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 3 Pin |
Case/Package | TO-220-3 |
Voltage Rating (DC) | 100 V |
Current Rating | 5.00 A |
Output Voltage | 100 V |
Output Current | 5 A |
Number of Positions | 3 Position |
Polarity | NPN |
Power Dissipation | 65 W |
Breakdown Voltage (Collector to Emitter) | 100 V |
Thermal Resistance | 62.5℃/W (RθJA) |
Continuous Collector Current | 5A |
hFE Min | 1000 @3A, 3V |
Input Power (Max) | 2 W |
DC Current Gain (hFE) | 1000 |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -65 ℃ |
Power Dissipation (Max) | 65 W |
Input Voltage | 2.5 V |
Show | |
Size-Length | 15.75 mm |
Size-Width | 4.83 mm |
Size-Height | 4.82 mm |
Operating Temperature | -65℃ ~ 150℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/12/17 |
ECCN Code | EAR99 |
