Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 3 Pin |
Case/Package | TO-220-3 |
Voltage Rating (DC) | 100 V |
Current Rating | 1.00 A |
Number of Positions | 3 Position |
Polarity | NPN |
Power Dissipation | 30 W |
Breakdown Voltage (Collector to Emitter) | 100 V |
hFE Min | 15 @1A, 4V |
hFE Max | 75 |
Input Power (Max) | 2 W |
DC Current Gain (hFE) | 75 |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -65 ℃ |
Power Dissipation (Max) | 2000 mW |
Show | |
Size-Length | 10.4 mm |
Size-Width | 4.6 mm |
Size-Height | 9.15 mm |
Material | Silicon |
Operating Temperature | 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2014/06/16 |
