Description
- OFFICE MACHINE HOUSEHOLD USE EQUIPMENT TRIAC DRIVERSOLID STATE RELAY
- The TOSHIBA TLP3051(S) and TLP3052(S) consists of a photo-triac optically coupled to a gallium arsenide infrared emitting diode in a six lead plastic DIP package.
- • Peak Off-State Voltage : 600V(Min)
- • Trigger LED Current : 15mA(Max) (TLP3051(S))
- 10mA(Max) (TLP3052(S))
- • On-State Current : 100mA(Max)
- • Isolation Voltage : 5000Vrms(Min)
- • UL Recognized : UL1577, File No.E67349
- • SEMKO Approved : SS EN60065
- SS EN60950, File No.9841111
- • BSI Approved : BS EN60065, File No.8385
- BS EN60950, File No.8386
- • Option (D4) type
- VDE approved: DIN EN60747-5-2
- Approved No. 40009302
- Maximum operating insulation voltage: 890VPK
- Highest permissible over voltage: 8000VPK
- (Note):When a EN60747-5-2 approved type is needed,
- please designate the "Option (D4)"
TLP3052 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 5 Pin |
| Case/Package | PDIP-6 |
| Output Voltage | 600 V |
| Power Dissipation | 330 mW |
| Operating Temperature (Max) | 100 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Size-Length | 7.12 mm |
| Size-Width | 6.4 mm |
| Size-Height | 3.65 mm |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
