Description
- Worried about sensitive components in your circuit? The voltage monitor TPS3513N voltage monitor IC from Texas Instruments can add an extra layer of protection from voltage spikes. This device has a maximum power dissipation of 1512 mW. Its maximum power dissipation is 1512 mW. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It has a typical reset threshold voltage of 3.3|5|12 V, with a minimum of 2.2|3.5|9 V and a maximum of 3.9|6.1|13.8 V. This voltage supervisor IC has an operating temperature range of -40 °C to 85 °C. This device has a minimum operating supply voltage of 4.5 V and a maximum of 15 V.
TPS3513N Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 14 Pin |
| Case/Package | PDIP-14 |
| Supply Voltage (DC) | 15.0V (max) |
| Supply Current | 1 mA |
| Power Dissipation | 1512 mW |
| Quiescent Current | 1.00 mA |
| Threshold Voltage | 3.3V,5V,12V |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 1512 mW |
| Supply Voltage (Max) | 15 V |
| Supply Voltage (Min) | 4.5 V |
| Show | |
| Size-Length | 19.3 mm |
| Size-Width | 6.35 mm |
| Size-Height | 4.57 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
