TPS65053RGET - TI
Manufacturer:
TI
ManyChip's Part#:
MC28947200
Category:
Power Management IC
Package:
VQFN-24
Datasheet:
Datasheet 3D Model
Description:
5Channel Power Management IC (PMIC) with two step down converters and 3 low-input voltage LDOs 24-VQFN -40℃ to 85℃d
Stock Locations:
Availability:
115 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.79

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TPS6505xx family of devices are integrated power management ICs for applications powered by one Li-Ion or Li-Polymer cell, which require multiple power rails. The TPS6505xx devices provide two highly efficient, 2.25-MHz step-down converters targeted at providing the core voltage and I/O voltage in a processor-based system. Both step-down converters enter a low power mode at light load for maximum efficiency across the widest possible range of load currents. For low noise applications the devices can be forced into fixed frequency PWM mode by pulling the MODE pin high. The TPS6505xx devices also integrate one 400-mA LDO and two 200-mA LDO voltage regulators. Each LDO operates with an input voltage range between 1.5 V and 6.5 V allowing them to be supplied from one of the step-down converters or directly from the main battery.

Show

TPS65053RGET Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	VQFN-24
Frequency	2.25 MHz
Supply Voltage (DC)	6.00 V
Output Voltage	6.00 V, 1.00 V (min)
Output Current	1.00 A
Number of Regulated Outputs	5 Output
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.5V ~ 6V
	Show
Size-Length	4 mm
Size-Width	4 mm
Size-Height	0.88 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
