Description
- Introduction
- The TPS65951 device is a power-management IC for mobile cellular handsets powered by a Li-ion, Li-ion polymer, or cobalt-nickel-manganese cell battery. It can be connected to an application processor and/or a modem. This optimized power-management IC is designed to support the specific power requirements of the OMAP processor devices. The TPS65951 contains several buck converters, low dropout (LDO) regulators, battery charger interface, and a host of other features and functions. The audio portion of the TPS65951 is an entire audio module with audio codecs, digital filters, input preamplifiers/amplifiers, and class D output amplifiers.
- This TPS65951 Data Manual presents the electrical and mechanical specifications for the TPS65951 device. It covers the following topics:
- • A description of the TPS65951 terminals: assignment, multiplexing, electrical characteristics, and functional description (see Section 2)
- • A presentation of the electrical characteristic requirements: maximum and recommended operating conditions, digital I/O characteristics (see Section 3)
- • The clock specifications: clock slicer, input and output clocks (see Section 4)
- • The audio/voice module with the electrical characteristics and the application schematics for the downlink and uplink path (see Section 5)
- • The power module including the power provider, power references, power control, the power consumption, and the power management with the sequence on and off (see Section 6)
- • The timing requirements and switching characteristics (ac timings) of the interfaces (see Section 7)
- • The battery charger interface (see Section 8)
- • A description of different modules: MADC and LED drivers (see Section 9 and Section 10)
- • The deboucing time (see Section 11)
- • A description of the external components for the application schematics (see Section 12)
- • The thermal resistance characteristics, device nomenclature, and mechanical data about the available packaging (see Section 13)
- • 1 A glossary of acronyms and abbreviations used in this data manual (see Section 14)
TPS65951A1ZGU Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 12 Pin |
| Case/Package | BGA-169 |
| Supply Voltage (DC) | 5.00 V |
| Number of Positions | 12 Position |
| Number of Regulated Outputs | 12 Output |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 5 V |
| Show | |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Each |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2014/12/17 |
| ECCN Code | 5A991.g |
