Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 8 Pin |
Case/Package | DIP-8 |
Supply Voltage (DC) | 3.00 V |
Operating Voltage | 2.7V ~ 16V |
Supply Current | 400 µA |
Number of Circuits | 2 Circuit |
Number of Channels | 2 Channel |
Number of Positions | 8 Position |
Common Mode Rejection Ratio | 60 dB |
Bandwidth | 800 kHz |
Slew Rate | 400 mV/μs |
Gain Bandwidth Product | 1.4 MHz |
Input Offset Voltage | 10 mV |
Input Bias Current | 1 pA |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -40 ℃ |
Supply Voltage | 2.7V ~ 16V |
Supply Voltage (Max) | 16 V |
Supply Voltage (Min) | 2.7 V |
Show | |
Size-Width | 6.35 mm |
Operating Temperature | -40℃ ~ 125℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/12/17 |
