Description

Control your system in your alternative way with this bicmos advanced phase shift resonant s UCC3895DWTRG4 soft switching PWM controller manufactured by Texas Instruments. Its output produces a current of 100(Max) mA. This soft switching controller has 4 outputs. You can operate this at a switching frequency of 1000 kHz. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This device has a minimum operating supply voltage of 10 V and a maximum of 16.5 V. This soft switching controller has an operating temperature range of 0 °C to 70 °C. This soft switching controller"s maximum duty cycle is 100 %.

Show

UCC3895DWTRG4 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SOIC-24
Frequency	1 MHz
Supply Voltage (DC)	10.0V (min)
Number of Outputs	4 Output
Output Voltage	250 mV
Output Current	10 mA
Power Dissipation	650 mW
Number of Regulated Outputs	4 Output
Switching Frequency	1 MHz
Topology	Buck
Duty Cycle	100 %
Maximum Duty Cycle	100 %
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	650 mW
Supply Voltage	10V ~ 16.5V
Supply Voltage (Max)	16.5 V
Supply Voltage (Min)	10 V
	Show
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
