Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 2 Pin |
Case/Package | DO-204AL |
Voltage Rating (DC) | 100 V |
Current Rating | 1 A |
Capacitance | 17 pF |
Output Current | 1 A |
Forward Voltage | 1 V |
Polarity | Standard |
Power Dissipation | 2.08 W |
Thermal Resistance | 60℃/W (RθJA) |
Reverse recovery time | 50 ns |
Forward Current | 1 A |
Max Forward Surge Current (Ifsm) | 30 A |
Maximum Forward Voltage (Max) | 1 V |
Forward Current (Max) | 1 A |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -65 ℃ |
Junction Temperature (Max) | 150 ℃ |
Show | |
Size-Length | 5.2 mm |
Size-Width | 2.72 mm |
Size-Height | 2.72 mm |
Weight | 0.111130138 kg |
Operating Temperature | -65℃ ~ 150℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
