Description
- Complementary Dual General Purpose Amplifier Transistor
- PNP and NPN Surface Mount
- Features
- • High Voltage and High Current: VCEO = 50 V, IC = 200 mA
- • High hFE: hFE = 200~400
- • Moisture Sensitivity Level: 1
- • ESD Rating − Human Body Model: 3A
- ESD Rating − Machine Model: C
- • NSV Prefix for Automotive and Other Applications Requiring
- Unique Site and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable
- • These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
UMZ1NT1G Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SC-70-6 |
| Frequency | 114 MHz |
| Voltage Rating (DC) | 50.0 V |
| Current Rating | 200 mA |
| Number of Positions | 3 Position |
| Polarity | NPN, PNP |
| Power Dissipation | 250 mW |
| Breakdown Voltage (Collector to Base) | 50.0 V |
| Breakdown Voltage (Collector to Emitter) | 50 V |
| Continuous Collector Current | 0.2A |
| hFE Min | 200 @2mA, 6V |
| Input Power (Max) | 250 mW |
| DC Current Gain (hFE) | 200 |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 385 mW |
| Show | |
| Size-Width | 1.25 mm |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
