Image is for your reference only,please check specifications for details

UUR1V470MCL1GS - Nichicon
Manufacturer:
Nichicon
ManyChip's Part#:
MC20815253
Category:
Aluminum Electrolytic Capacitors, Aluminum Capacitors, Capacitors Aluminum
Package:
SMD
Datasheet:
Datasheet 3D Model
Description:
47uF ±20% 35V Φ8mm 6.2mm
Stock Locations:
Availability:
0 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

This electrolytic UUR1V470MCL1GS aluminum capacitor from Nichicon has a relatively high equivalent series resistance which allows it to generate high heat for a given current level. It can withstand a voltage of 35 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 85 °C. It has a tolerance of 20%. Its capacitance value is 47uF. This product is 6.2 mm tall with a diameter of 8 mm. Its leakage current is 49.35@1Min μA.

Show

UUR1V470MCL1GS Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SMD
Voltage Rating (DC)	35.0 V
Capacitance	47 µF
Capacitance Tolerance	±20 %
Part Family	UUR
Ripple Current	105 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	35 V
	Show
Size-Height	6.2 mm
Size-Diameter	8.00 mm
Dielectric Material	Aluminum Electrolytic
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
Minimum Packing Quantity	1000
Life (Hours)	2000 h
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
