- VIPER28LN - ST Microelectronics
-
Manufacturer:ST Microelectronics
-
ManyChip's Part#:MC14897353
-
Category:AC to DC Converter, AC/DC Power Module
-
RoHS:Lead free / RoHS Compliant
-
Datasheet:Datasheet 3D Model
-
Description:AC to DC Switching Converter Off-Line Switcher 54kHz to 66kHz Tube 7Pin PDIP
-
Stock Locations:
-
Availability:111 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.59
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Description
- The device is an off-line converter with an 800 V rugged power section, a PWM control, two levels of over-current protection, over-voltage and overload protections, hysteretic thermal protection, soft-start and safe auto-restart after any fault condition removal. Burst mode operation and device very low consumption help to meet the standby energy saving regulations.
- Features
- ■ 800 V avalanche rugged power section
- ■ PWM operation with adjustable limiting current
- ■ 30 mW stand-by power at 265 Vac
- ■ Operating frequency:
- – 60 kHz for L type
- – 115 kHz for H type
- ■ Frequency jittering for low EMC
- ■ Output overvoltage protection
- ■ High primary current protection (2nd OCP)
- ■ Extra power timer for peak current management
- ■ On-board soft-start
- ■ Safe auto-restart after a fault condition
- ■ Hysteretic thermal shutdown
- Application
- ■ Auxiliary power supply for consumer and home equipment
- ■ ATX auxiliary power supply
- ■ Low / medium power AC-DC adapters
- ■ SMPS for set-top boxes, DVD players and recorders, white goods
VIPER28LN Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 7 Pin |
| Case/Package | DIP-8 |
| Power Rating | 16 W |
| Number of Outputs | 1 Output |
| Output Voltage | 800 V |
| Output Current | 1.2 A |
| Breakdown Voltage | 800 V |
| Number of Positions | 7 Position |
| Output Power | 20 W |
| Switching Frequency | 60 kHz |
| Duty Cycle | 80 % |
| Input Voltage (Max) | 23.5 V |
| Input Voltage (Min) | 8.5 V |
| Input Voltage (AC Max) | 265 v |
| Input Voltage (AC Min) | 85 v |
| Output Voltage (Max) | 800 V |
| Maximum Duty Cycle | 80 % |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 8.5V ~ 23.5V |
| Supply Voltage (Max) | 23.5 V |
| Supply Voltage (Min) | 8.5 V |
| Input Voltage | 8.5V ~ 23.5V |
| Show | |
| Size-Length | 10.16 mm |
| Size-Width | 8.26 mm |
| Size-Height | 4.95 mm |
| Operating Temperature | -40℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
