22AC2 - Honeywell
Manufacturer:
Honeywell
ManyChip's Part#:
MC33512480
Category:
Interlock Switch, Switch Safety Interlock
Package:
125
Datasheet:
Datasheet 3D Model
Description:
Switch Safety Interlock N.O./N.C. SPDT Rod 15A 250VAC 250VDC 248.57VA Screw Screw Mount
Stock Locations:
Availability:
247 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 37.85

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 22AC2 is a single-pole double-throw (SPDT) safety interlock Door Switch with a 3-position push-momentary pull-maintained threaded plunger actuator, screw terminations and ON-OFF function. The MICRO SWITCH™ AC series switch enables circuit testing with POWER ON by manually pulling a rod actuator to the maintained-ON position. The AC series switch is a compact switch assembly designed for equipment applications. When the equipment which is electrically interlocked through the AC series switch is opened, the action of the AC series switch disconnects the electrical power. The AC series switch can provide an electrical signal to an annunciator circuit such as a light or horn indicating the door or panel is open. Another feature that is common to most AC series switch assemblies is a pull-to-override position which allows the service door to be open and yet apply electrical power through the switch assembly.
Closing the door resets the switch
Versatile mounting bracket for side or end mounting
Reliable performance
Mounting ease
Wide electrical range

Show

22AC2 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Chassis, Screw Terminals
Case/Package	125
Voltage Rating (DC)	125 V
Actuator Type	Rod
Voltage Rating (AC)	125 V
Current Rating	160mA (AC), 160mA (DC)
Contacts Type	SPDT
Number of Positions	2 Position
Contact Current Rating	15.0 A
Current Rating (Max)	15A @250VAC
Input Power (Max)	248.57 VA
Operating Temperature (Max)	82 ℃
Operating Temperature (Min)	-53 ℃
Voltage Rating	250 VAC
Voltage Rating (DC Max)	250 V
Voltage Rating (AC Max)	250 V
	Show
Size-Length	40.49 mm
Size-Height	33.02 mm
Operating Temperature	-53℃ ~ 82℃
Housing Material	Polyester
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
HTS Code	8536509055
ECCN Code	EAR99
