Description
- **RIF1 Power Relay Module**
- Professional range of power relays that come with a base, suppressor and retaining bracket that benefits from a universal plug in design.
2903330 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | DIN Rail |
| Number of Pins | 8 Pin |
| Voltage Rating (DC) | 250 V |
| Voltage Rating (AC) | 250 V |
| Contact Current Rating | 25 A |
| Coil Voltage | 24 VDC |
| Coil Current | 18 mA |
| Coil Resistance | 1.44 kΩ |
| Coil Voltage (DC) | 24 V |
| Coil Power | 400 mW |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Size-Length | 16 mm |
| Size-Width | 16 mm |
| Size-Height | 93 mm |
| Contact Material | Silver Nickel, Gold |
| Operating Temperature | -40℃ ~ 70℃ |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
