Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | PCB |
Number of Pins | 14 Pin |
Case/Package | - |
Voltage Rating (DC) | 250 V |
Voltage Rating (AC) | 250 V |
Contact Current Rating | 6 A |
Coil Voltage | 24 VDC |
Coil Current | 41 mA |
Coil Resistance | 585.36 Ω |
Current Rating (Max) | 6 A |
Coil Voltage (DC) | 24 V |
Coil Power | 77 mW |
Operating Temperature (Max) | 70 ℃ |
Operating Temperature (Min) | -40 ℃ |
Voltage Rating (DC Max) | 250 V |
Voltage Rating (AC Max) | 250 V |
Show | |
Size-Length | 21.2 mm |
Size-Width | 21.2 mm |
Size-Height | 35.6 mm |
Contact Material | Silver Nickel |
Operating Temperature | -40℃ ~ 70℃ |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | RoHS Compliant |
ECCN Code | EAR99 |
