4300.0701 - Schurter
Manufacturer:
Schurter
ManyChip's Part#:
MC14292663
Category:
Tip Plug, Tip Jack
Package:
-
Datasheet:
Datasheet 3D Model
Description:
Mains Power Connector, 15A, 125/250VAC, Female, Solder Terminal, ROHS COMPLIANT
Stock Locations:
Availability:
267 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.33

Updated at 27/06/2026 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 4300.0701 is a front snap-in panel-mount Power Entry Connector with solder terminals. The connector is made with black thermoplastic housing. It is designed for standard applications and suitable for use in equipment according to IEC/UL 60950. Version with insulation walls between terminals designed for use in power distribution units for household and commercial furnishings required to meet the UL 962 spill test.
NEMA line outlet 5-15R
UL94V-0 Flammability rating
-25 to 60°C Operating temperature range

Show

4300.0701 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Panel, Snap-In, Solder Lug
Case/Package	-
Number of Contacts	3 Contact
Gender	Female
Voltage Rating (DC)	125 V
Voltage Rating (AC)	125 V
Current Rating	15 A
Number of Positions	3 Position
Current Rating (Max)	15 A
Operating Temperature (Max)	60 ℃
Operating Temperature (Min)	-25 ℃
Voltage Rating (Max)	125 VAC
Voltage Rating	125 V
	Show
Size-Length	27 mm
Size-Width	32.5 mm
Size-Height	27 mm
Contact Material	Brass
Material	Nylon
Operating Temperature	-25℃ ~ 60℃
Housing Material	Thermoplastic
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2016/06/20
HTS Code	8536698000
ECCN Code	EAR99
