Image is for your reference only,please check specifications for details

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 60B104C is a surface mount unshielded Power Inductor with pure tin pin finish. This 6000B series high current power inductor supports 100kHz frequency and ±15% inductance tolerance. The maximum DC current is the value at which the inductance falls to 75% of its nominal value or when its temperature rise reaches 40°C, whichever is sooner.
High energy storage
Very low resistance
J-STD-020D.1 Reflow

Show

60B104C Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Case/Package	27mm x 19.5mm x 20mm
Current Rating	7.5 A
Capacitance Tolerance	±15 %
Inductance	100 µH
Self Resonant Frequency	4.98 MHz
Inductance Tolerance	±15 %
Test Frequency	100 kHz
DC Resistance (DCR)	≤25 mΩ
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Resistance (DC Max)	0.025 Ω
	Show
Size-Length	27 mm
Size-Width	19.5 mm
Size-Height	20 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
