Description

The NTA0515MC is a 2-output 1W board-mount isolated DC to DC Converter employ lead frame technology and transfer moulding technique. Co-planarity of the lead positions is based upon IEC 191-6:1990. The NTA series miniature surface mounted DC/DC converter is suitable for all applications where high volume production is envisaged.
Efficiency up to 78%
Footprint over pins 1.64cm²
Internal SMD construction
Toroidal magnetics
1kVDC Isolation
MTTF up to 2.1 million hours
1.36W/cm³ Power density
No heatsink required
Multi-layer ceramic capacitors
-40 to +85°C Wide operating temperature range

Show

NTA0515MC Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	SMD-18
Supply Voltage (DC)	5.00 V
Power Rating	1 W
Number of Outputs	2 Output
Input Voltage (DC)	4.50V ~ 5.50V
Output Voltage	±15 VDC
Output Current	33.0 mA
Flammability Rating	UL 94 V-0
Output Power	1 W
Isolation Voltage	1 kV
Input Voltage (Max)	5.5 V
Input Voltage (Min)	4.5 V
Input Voltage (DC Max)	5.5 V
Input Voltage (DC Min)	4.5 v
Output Current (Max)	33mA, 33mA
Input Power (Max)	1 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	4.5VDC ~ 5.5VDC
	Show
Size-Length	15.24 mm
Size-Width	7.7 mm
Size-Height	6.6 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
