Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- 4.7µH Shielded Wirewound Inductor 6.2A 19.5mOhm Max Nonstandard
7447797470 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package | 10.2mm x 10.2mm x 4.5mm |
| Current Rating | 6.2 A |
| Capacitance Tolerance | ±20 % |
| Inductance | 4.7 µH |
| Self Resonant Frequency | 45.0 MHz |
| Part Family | WE-PDF |
| Resonant Frequency | 52 MHz |
| Inductance Tolerance | ±20 % |
| DC Resistance (DCR) | 19.5 mΩ |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Resistance (DC Max) | 0.0195 Ω |
| Show | |
| Size-Length | 10.2 mm |
| Size-Height | 4.5 mm |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2014/06/16 |
