74HC151D - NXP
Manufacturer:
NXP
ManyChip's Part#:
MC85242631
Category:
Logic Controller, Logic IC
Package:
SOIC
Datasheet:
Datasheet 3D Model
Description:
NXP 74HC151D Multiplexer, HC Family, 1 Gate, 8Input, 2 Output, 5.2mA, 2V to 6V, SOIC-16
Stock Locations:
Availability:
1,651 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.45

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 74HC151D is a 8-bit Multiplexer with eight binary inputs (I0 to I7), three select inputs (S0 to S2) and an enable input (E\\). One of the eight binary inputs is selected by the select inputs and routed to the complementary outputs (Y and Y\\). A high on E\ forces the output Y low and output Y\ high. Inputs also include clamp diodes that enable the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Low-power dissipation
Non-inverting data path
CMOS Input levels
Complies with JEDEC standard No. 7A

Show

74HC151D Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC
Supply Voltage (DC)	2.00V (min)
Number of Outputs	2 Output
Number of Circuits	1 Circuit
Number of Positions	16 Position
Polarity	Non-Inverting, Inverting
Power Dissipation	0.5 W
Number of Gates	1 Gate
Number of Inputs	8 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	6 V
Supply Voltage (Min)	2 V
	Show
Size-Length	10 mm
Size-Width	4 mm
Size-Height	1.45 mm
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
