Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 2 Pin |
Case/Package | DO-41 |
Voltage Rating (DC) | 11.0 V |
Capacitance Tolerance | ±5 % |
Power Rating | 1.00 W |
Breakdown Voltage | 11.0 V |
Number of Positions | 2 Position |
Forward Voltage | 1.2V @200mA |
Power Dissipation | 1 W |
Test Current | 20 mA |
Zener Voltage | 11 V |
Maximum Forward Voltage (Max) | 1.2V @200mA |
Input Power (Max) | 1 W |
Operating Temperature (Max) | 200 ℃ |
Operating Temperature (Min) | -65 ℃ |
Power Dissipation (Max) | 1 W |
Show | |
Size-Length | 5.21 mm |
Size-Width | 2.72 mm |
Size-Height | 2.72 mm |
Operating Temperature | -65℃ ~ 200℃ |
Product Lifecycle Status | Active |
Packaging | Bulk |
RoHS | Non-Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/06/15 |
ECCN Code | EAR99 |
