74HC4051D - NXP
Manufacturer:
NXP
ManyChip's Part#:
MC9454263
Category:
Logic Control, Logic Gate IC
Package:
SOIC-16
Datasheet:
Datasheet 3D Model
Description:
IC 8Channel, SGL ENDED MULTIPLEXER, PDSO16, 3.9MM, PLASTIC, MS-012, SOT-109-1, SOP-16, Multiplexer or Switch
Stock Locations:
Availability:
9,900 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.12

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 74HC4051D is an 8 channel analogue multiplexer/demultiplexer in 16 pin SOIC package. This high speed Si-gate CMOS device is pin compatible with low power schottky TTL (LSTTL). The device is specified in compliance with JEDEC standard JESD 7A. The 74HC4051D has three digital select inputs (S0 to S2), active LOW enable input, eight independent inputs/outputs (Y0 to Y7) and common input/output (Z). When active LOW enable input is LOW, one of the eight switches is selected (low impedance ON state) by S0 to S2. With active LOW enable input HIGH, all switches are in high impedance OFF state independent of S0 to S2. The analogue inputs/outputs (Y0 to Y7 and Z) can swing between VCC as positive limit and VEE as negative limit. To operate the device as digital multiplexer/demultiplexer, VEE is connected to GND.
Wide analogue input voltage range from -5V to 5V
Low ON resistance of 80 ohm (typical) at VCC - VEE=4.5V
Logic level translation to enable 5V logic to communicate with ±5V analogue signals
Built-in break before make feature
Features ESD protection
Supply voltage range from 2V to 10V
Ambient temperature range from -40°C to 125°C

Show

74HC4051D Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	9.00 V
Number of Outputs	8 Output
Number of Circuits	1 Circuit
Number of Positions	16 Position
Polarity	Non-Inverting
Power Dissipation	500 mW
Number of Gates	1 Gate
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	180 MHz
Supply Voltage	2V ~ 10V
	Show
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
