Image is for your reference only,please check specifications for details
- VEML6075 - VISHAY
-
Manufacturer:VISHAY
-
ManyChip's Part#:MC22331125
-
Category:Optical Sensor
-
RoHS:Lead free / RoHS Compliant
-
Datasheet:Datasheet 3D Model
-
Description:VEML6075 Series 3.6V 2 x 1.25 x 1mm UVA and UVB Light Sensor with I2C Interface
-
Stock Locations:
-
Availability:61 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.16
Updated at 03/12/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The VEML6075 from Vishay is a UVA and UVB light sensor with I2C interface in 4 pin OPLGA package. This device incorporates photodiode, amplifiers and analogue / digital circuits into a single chip using a CMOS process. When the UV sensor is applied, it is able to detect UVA and UVB intensity to provide a measure of the signal strength as well as allowing for UVI measurement. It provides excellent temperature compensation capability for keeping the output stable under changing temperature. It"s functionality is easily operated via the simple command format of I2C (SMBus compatible) interface protocol. The reliable performance of UV radiation measurement under long time solar UV exposure.
VEML6075 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 4 Pin |
| Case/Package | OPLGA-4 |
| Output Current | 400 µA |
| Supply Current | 480 µA |
| Wavelength | 365nm,330nm |
| Peak Wavelength | 330 nm,365 nm |
| Rise Time | 1000 ns |
| Fall Time | 300 ns |
| Fall Time (Max) | 300 ns |
| Fall Time (Max) | 300 ns |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 1.7V ~ 3.6V |
| Show | |
| Size-Length | 2 mm |
| Size-Width | 1.25 mm |
| Size-Height | 1 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
Order guide
-
TT in advance (bank transfer), Western Union, Credit card,
PayPal. Customer is responsible for shipping fee, bank
charges, duties and taxes.
-
- You can choose whether shipping charges will be charged through your shipping account or by us.
- Please confirm with the logistics company in advance for remote areas.
(Additional charges ($35-$50) may apply for delivery in these areas)
- Delivery date: usually 2 to 7 working days.
- A tracking number will be sent after your order ships.
- - Carefully inspected and packed by ManyChip warehouse - Vacuum packaging - Anti-static packaging - Shockproof foam
- The terms here are for reference only, the actual terms are subject to the sales quotation. - Please confirm product specifications when ordering. - MOQ refers to the minimum order quantity required to purchase each part. - If you have special ordering instructions, please indicate them on the ordering page. - Inspection (PSI) will be performed prior to shipment.
- - Income Quality Control (IQC), 1000+ qualified dealers. - Chips are tested by authoritative organizations to ensure the quality, authenticity and safety of your device. - Decapsulation control - X-ray control - XRF inspection - Electrical testing - Surface testing -Digital components warehouse, covering an area of 800 square meters, with constant temperature and humidity
