Description

Are you looking for a device that can regulate the input voltage into your circuit? Fairchild Semiconductor"s 74VCX163245MTD level translator is the perfect solution for you. With a 3-state output, this is power management at its best. This level shifter has a minimum operating temperature of -40 °C and a maximum of 85 °C. This product comes in rail packaging to keep individual parts separated and protected. This device has a typical operating supply voltage of 1.8/2.5|1.8/3.3|2.5/3.3 V. Its minimum operating supply voltage of 1.65/2.3 V, while its maximum is 2.7/3.6 V.

Show

74VCX163245MTD Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	48 Pin
Case/Package	TSSOP-48
Supply Voltage (DC)	2.50 V, 2.70 V (max)
Number of Outputs	16 Output
Output Current	24.0 mA
Number of Circuits	2 Circuit
Number of Channels	16 Channel
Number of Positions	48 Position
Number of Bits	16 Bit
Number of Inputs	20 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	1.65.3.6 VDC
Supply Voltage (Max)	2.7 V
Supply Voltage (Min)	1.65 V
	Show
Size-Length	12.5 mm
Size-Width	6.1 mm
Size-Height	0.9 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
