AD5412AREZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1979400
Category:
Digital to Analog, DAC IC
Package:
TSSOP-24
Datasheet:
Datasheet 3D Model
Description:
Digital to Analog Converter, 12Bit, 40KSPS, Serial, 2.7V to 5.5V, 10.8V to 40V, TSSOP, 24Pins
Stock Locations:
Availability:
1,257 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.22

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5412AREZ is a precision fully integrated 12-bit Digital-to-analog Converter (DAC) offering a programmable current source and programmable voltage output designed to meet the requirements of industrial process control applications. The LFCSP version of this product has a CAP2 pin so that the HART signals can be coupled onto the current output of the AD5412. Analog outputs are short and open-circuit protected and can drive capacitive loads of 1µF. The device operates with an AVDD power supply range from 10.8 to 40V. The flexible serial interface is SPI and MICROWIRE™- compatible and can be operated in 3-wire mode to minimize the digital isolation required in isolated applications. The device also includes a power-on-reset function, ensuring that the device powers up in a known state. The part also includes an asynchronous clear pin (CLEAR) that sets the outputs to zero-scale/midscale voltage output or the low end of the selected current range.
Flexible serial digital interface
On-chip output fault detection
On-chip reference - 10ppm/°C maximum

Show

AD5412AREZ Specifications
