AD5676BRUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1483972
Category:
Digital to Analog, DAC IC
Package:
TSSOP-20
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD5676BRUZ Digital to Analogue Converter, Octal, 16Bit, Serial, 2.7V to 5.5V, TSSOP, 20Pins
Stock Locations:
Availability:
288 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 13.95

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5676BRUZ is a low power octal 16-bit buffered voltage output Digital-to-analog Converter (DAC) operates from a single 2.7 to 5.5V supply and is guaranteed monotonic by design. The device includes a gain select pin, giving a full-scale output of VREF or 2 x VREF. The internal power-on reset circuit and the RSTSEL pin of the AD5676 ensures that the output DAC power up to zero scale or midscale and then remain there until a valid write takes place. The AD5676 contains a per channel power-down mode that typically reduces the current consumption of the device to 1µA. The AD5676 employs a versatile serial peripheral interface (SPI) that operates at clock rates up to 50MHz and contains a VLOGIC pin intended for 1.8 to 5.5V logic.
High performance
Wide operating ranges
Easy implementation
Robust 2kV HBM and 1.5kV FICDM ESD rating

Show

AD5676BRUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	TSSOP-20
Number of Outputs	8 Output
Number of Channels	8 Channel
Number of Positions	20 Position
Number of Bits	16 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	8 DAC
Supply Voltage	2.7V ~ 5.5V
	Show
Size-Length	6.6 mm
Size-Width	4.5 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99
