Description

The AD597ARZ is a monolithic temperature Set-point Controller which has been optimized for use at elevated temperatures such as those found in oven control applications. The device cold junction compensates and amplifies a type J or K thermocouple input to derive an internal signal proportional to temperature. The internal signal is then compared with an externally applied set-point voltage to yield a low impedance switched output voltage. Dead-Band or switching hysteresis can be programmed using a single external resistor. Alternately, this can be configured to provide a voltage output (10mV/°C) directly from a type J or K thermocouple signal. It can also be used as a stand-alone voltage output temperature sensor.
Calibration accuracy
10mV/°C Temperature proportional operation
Built-in ice point compensation
ON/OFF Temperature set-point operation
Programmable switching hysteresis
High impedance differential input

Show

AD597ARZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	30.0 V, 30.0 V (max)
Output Voltage	28 V
Output Current	5 mA
Supply Current	300 µA
Number of Positions	8 Position
Quiescent Current	300 µA
Gain Bandwidth Product	15 kHz
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	±4℃ (Max)
Supply Voltage	5V ~ 30V
Supply Voltage (Max)	30 V
Supply Voltage (Min)	5 V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
