AD627ARZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC102489
Category:
Instrumentation Amplifier IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
Instrument Amplifier, 1 Amplifier, 200μV, 0.07V/µs, 80kHz, ± 1.1V to ± 18V, SOIC
Stock Locations:
Availability:
245 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 7.14

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD627ARZ is a Micropower Single and Dual Supply Rail-to-rail Instrumentation Amplifier that delivers rail to rail output swing on single and dual (+2.2V to ±18V) supplies. The AD627 provides excellent AC and DC specifications while operating at only 85µA maximum. The AD627 offers superior flexibility by allowing the user to set the gain of the device with a single external resistor while conforming to the 8-lead industry-standard pinout configuration. With no external resistor, it is configured for a gain of 5. With an external resistor, it can be set to a gain of up to 1000. Single-supply operation, low power consumption and rail to rail output swing makes it ideal for battery-powered applications. Its rail to rail output stage maximizes dynamic range when operating from low supply voltages. Dual-supply operation (±15V) and low power consumption makes it ideal for industrial applications including 4mA to 20mA loop-powered systems.
Easy to use
Higher performance than discrete design
Rail-to-rail output swing
High accuracy DC performance
800kHz Bandwidth (G = +5)
135µs Settling time to 0.01% (G = +5, 5V step)
0.03% Typical gain accuracy (G = +5)
ESD sensitive device, take proper precaution while handling the device.

Show

AD627ARZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	18.0 V
Operating Voltage	2.2V ~ 36V
Supply Current	60 µA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	0.8 W
Common Mode Rejection Ratio	77 dB
Bandwidth	80 kHz
Slew Rate	70.0 mV/μs
Input Offset Voltage	200 µV
Input Bias Current	2 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	80 kHz
Power Dissipation (Max)	800 mW
Minimum CMRR Range	77 dB
Supply Voltage (Max)	30V ~ 50V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
HTS Code	8542330000
ECCN Code	EAR99
