AD811ANZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC375440
Category:
Video Amplifier, CATV Amplifier IC
Package:
DIP-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD811ANZ Video Amplifier, 1 Amplifiers, 140MHz, 2500V/µs, -40℃, 85℃, 100mA
Stock Locations:
Availability:
7 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 11.1

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD811ANZ is a High Performance Video Operational Amplifier optimized for broadcast-quality video systems. The -3dB bandwidth of 120MHz at a gain of +2 and the differential gain and phase of 0.01% and 0.01° (RL = 150R) make it an excellent choice for all video systems. The AD811 is designed to meet a stringent 0.1dB gain flatness specification to a bandwidth of 35MHz (G = +2) in addition to low differential gain and phase errors. This performance is achieved whether driving one or two back-terminated 75R cables, with a low power supply current of 16.5mA. The op amp is specified over a power supply range of ±4.5 to ±18V. It is also excellent for pulsed applications where transient response is critical. It can achieve a maximum slew rate of greater than 2500V/µs with a settling time of less than 25ns to 0.1% on a 2V step and 65ns to 0.01% on a 10V step.
High speed
25ns Settling time to 0.1% (for a 2V step)
65ns Settling time to 0.01% (for a 10V step)
Excellent video performance (RL = 150R)
0.01% Differential gain
0.01° Differential phase
1.9nV/√Hz Voltage noise
Low distortion
-74dB at 10MHz THD
Flexible operation
3mV Maximum input offset voltage
ESD sensitive device, take proper precaution while handling the device.

Show

AD811ANZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Output Current	100 mA
Supply Current	16.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	56 dB
Input Capacitance	7.50 pF
Bandwidth	140 MHz
Slew Rate	2.50 kV/μs
Input Impedance	1.50 MΩ
Input Offset Voltage	3 mV
Input Bias Current	10000 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	140 MHz
Gain Bandwidth	140 MHz
Minimum CMRR Range	56 dB
	Show
Size-Length	9.27 mm
Size-Width	7.24 mm
Size-Height	3.43 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
