Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 8 Pin |
Case/Package | SOIC-8 |
Supply Voltage (DC) | 5.00 V |
Output Current | 95mA @5V |
Supply Current | 20 mA |
Number of Circuits | 1 Circuit |
Number of Channels | 1 Channel |
Number of Positions | 8 Position |
Power Dissipation | 550 mW |
Common Mode Rejection Ratio | 77 dB |
Bandwidth | 320 MHz |
Slew Rate | 1.15 kV/μs |
Gain Bandwidth Product | 250 MHz |
Gain | 1.00 dB |
Input Offset Voltage | 3.5 mV |
Input Bias Current | 7000 nA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Gain Bandwidth | 320 MHz |
Power Dissipation (Max) | 550 mW |
Minimum CMRR Range | 70 dB |
Supply Voltage | 2.7.11 VDC |
Supply Voltage (Max) | 11 V |
Supply Voltage (Min) | 3 V |
Show | |
Size-Length | 5 mm |
Size-Width | 4 mm |
Size-Height | 1.5 mm |
Operating Temperature | -40℃ ~ 85℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
Mil-Spec | Yes |
REACH SVHC Compliance Edition | 2014/06/16 |
