AD8139ARDZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC329900
Category:
Operational Amplifier, OP Amp IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
Differential Amplifier, ADC Driver, 1 Amplifiers, 500μV, 1.001dB, 440MHz, -40℃, 125℃
Stock Locations:
Availability:
278 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.06

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8139ARDZ is a Low Noise Rail-to-rail Differential ADC Driver ideal choice for driving ADCs with resolutions to 18-bits. It is easy to apply and its internal common-mode feedback architecture allows its output common-mode voltage to be controlled by the voltage applied to one pin. The internal feedback loop also provides outstanding output balance as well as suppression of even-order harmonic distortion products. Simple external feedback networks consisting of four resistors determine the closed-loop gain of the amplifier. This ADC driver is manufactured on proprietary, second-generation XFCB process, enabling it to achieve low levels of distortion with input voltage noise of only 2.25nV/√Hz.
Low noise
Low harmonic distortion
High speed
69dB Output balance at 1MHz
80dB DC CMRR
±0.5mV Maximum low offset
0.5µA Maximum low input offset current
Differential-to-differential or single-ended-to-differential operation
Adjustable output common-mode voltage
ESD sensitive device, take proper precaution while handling the device.
