Image is for your reference only,please check specifications for details

AD8417WBRZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC434844
Category:
Amplifier, Buffer IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
SP Amp Zero Drift Amplifier Single 2.75V/5.5V Automotive 8Pin SOIC N Tube
Stock Locations:
Availability:
226 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.82

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

**GENERAL DESCRIPTION**
The AD8417 is a high voltage, high resolution current shunt amplifier. It features an initial gain of 60 V/V, with a maximum ±0.3% gain error over the entire temperature range. The buffered output voltage directly interfaces with any typical converter. The AD8417 offers excellent input common-mode rejection from −2 V to +70 V. The AD8417 performs bidirectional current measurements across a shunt resistor in a variety of
automotive and industrial applications, including motor control, power management, and solenoid control.
**FEATURES**
**Typical 0.1 µV/°C offset drift**
**Maximum ±400 µV voltage offset over full temperature range**
**2.7 V to 5.5 V power supply operating range**
**Electromagnetic interference (EMI) filters Included**
**High common-mode input voltage range**
** −2 V to +70 V continuous**
** −4 V to +85 V survival**
**Initial gain = 60 V/V**
**Wide operating temperature range: −40°C to +125°C**
**Bidirectional operation**
**Available in 8-lead SOIC and 8-lead MSOP**
**Common-mode rejection ratio (CMRR): 86 dB, dc to 10 kHz**
**Qualified for automotive applications**
**APPLICATIONS**
**High-side current sensing in**
** Motor controls**
** Solenoid controls**
** Power management**
**Low-side current sensing**
**Diagnostic protection**
